DATWYLER 418070

RJ45 Module KU-T 1/8 Tool-less, Cat. 6, Unshielded

DESCRIPTION
For the transmission of digital and analogue voice, video and data signals.
Suitable for all Class D applications respectively Class E Channels in accordance with ISO/IEC 11801, EN 50173-1 and TIA/EIA 568-B.2-10. Housing made of high-impact resistant,
flame retardant compound, UL94V-0 rated, with Keystone mounting clip.
Contact spring with phosphor bronze alloy, plated with gold.
IDC made of phosphor bronze alloy. Information:
Suitable for the same faceplates and surface mount boxes as Datwyler’s shielded Keystone modules (KS-T).
MECHANICAL PROPERTIES
Solid copper wire 0.40 mm (AWG 26) to 0.65 mm (AWG 22)
Re-connection for AWG 22, AWG 23 and AWG 24
when using the same or bigger wire diameter
Stranded copper wire AWG 26 (with 7 bare stranded wires), re-usable once
Diameter over insulation 0.70 mm to 1.40 mm (1.60 mm)
Temperature range storing: – 40° C to + 70° C
during installation: – 10° C to + 60° C
in operation: – 20° C to + 60° C

 BELDEN AX101320

Cat6 UTP Module, White (Face plate side)

DESCRIPTION

CAT6+ KeyConnect Jacks are available in several colors.

Height: 0.88 in
Width: 0.64 in
Depth: 1.29 in
