Faceplates & Back Boxes
108258427 COMMSCOPE L Type Flush Mounted Faceplate, One Port White
9.57 AEDAdd to cartCOMMSCOPE 108258427
L Type Flush Mounted Faceplate, one port white
General Specifications
Application Used with M Series modular information outlet
Color White
Mounting Flush
Total Ports, quantity 1
Dimensions
Height 4.56 in | 115.824 mm
Width 2.81 in | 71.374 mm
Depth 0.29 in | 7.366 mm
Material Specifications
Material Type High-impact, flame retardant, thermoplastic
Environmental Specifications
Flammability Rating UL 94 V-0
Safety Standard UL | cUL
Packaging and Weights
Packaging quantity 1
Weight, net 0.08 lb | 0.036 kg240639 Datwyler Faceplate flat, single, white.
9.00 AEDAdd to cart240639 Datwyler Faceplate flat, single, white
DESCRIPTION
Applicable for the installation of 1 respectively 2 modules with Keystone fitting (shielded or unshielded) or 1 respectively 2 LC Duplex or SC Simplex adapters. The Keystone modules and FO adapters are easily fitted into the faceplates. The universal module frame can be swapped or replaced from the front side. Integrated sliding dust shutters (removable) serve as covers for unused ports (available in white, blue, yellow or red). Labelling field with transparent cover. Supplied with labelling strips. Delivery without Keystone modules / FO adapters.
- Cat6 Accessories, Cat6a Accessories, DATWYLER, Faceplates & Back Boxes, Structured Cabling, Structured Networking
240640 Datwyler Faceplate flat, double, white
11.50 AEDAdd to cart240640 Datwyler Faceplate flat, double, white
DESCRIPTIPON
Applicable for the installation of 1 respectively 2 modules with Keystone fitting (shielded or unshielded) or 1 respectively 2 LC Duplex or SC Simplex adapters. The Keystone modules and FO adapters are easily fitted into the faceplates. The universal module frame can be swapped or replaced from the front side. Integrated sliding dust shutters (removable) serve as covers for unused ports (available in white, blue, yellow or red). Labelling field with transparent cover. Supplied with labelling strips. Delivery without Keystone modules / FO adapters.
240642 DATWYLER Faceplate Angle, 2-Ports with Keystone Fitting – BS
12.00 AEDAdd to cartDATWYLER 240642
Faceplate Angle, 2-Ports with Keystone Fitting – BS
DESCRIPTION
Applicable for the installation of 1 respectively 2 modules with Keystone fitting (shielded or unshielded)
or 1 respectively 2 LC Duplex or SC Simplex adapters.
The Keystone modules and FO adapters are easily fitted into the faceplates.
The universal module frame can be swapped or replaced from the front side.
Integrated sliding dust shutters (removable) serve as covers for unused ports (available in white, blue, yellow or red).
2 label areas: 1 in module frame (with transparent label cover), 1 on face plate cover.
Supplied with labelling strips.
Delivery without Keystone modules / FO adapters.760072199 COMMSCOPE M13SP-L 3-port Single Gang Stainless Steel Faceplate with Label
64.71 AEDAdd to cartCOMMSCOPE 760072199
M13SP-L 3-port Single Gang Stainless Steel Faceplate with Label
General Specifications
Application Used with M Series modular information outlet
Mounting Flush
Total Ports, quantity 3
Dimensions
Height 4.5 in | 114.3 mm
Width 2.75 in | 69.85 mm
Depth 0.16 in | 4.064 mm
Material Specifications
Material Type Stainless steel
Environmental Specifications
Safety Standard UL | cUL
Packaging and Weights
Packaging quantity 1
Weight, net 0.16 lb | 0.073 kg760072207 COMMSCOPE 4-port Single Gang Stainless Steel Faceplate with Label
64.71 AEDAdd to cartCOMMSCOPE 760072207
M14SP-L 4-port Single Gang Stainless Steel Faceplate with Label
General Specifications
Application Used with M Series modular information outlet
Mounting Flush
Total Ports, quantity 4
Dimensions
Height 4.5 in | 114.3 mm
Width 2.75 in | 69.85 mm
Depth 0.16 in | 4.064 mm
Material Specifications
Material Type Stainless steel- BRAND-REX, Cat5E, Cat6 Accessories, Cat6 Modules & Outlets, Cat6a Accessories, Faceplates & Back Boxes, Leviton, Structured Networking
MMCWDOUNI071 LEVITON 86 x 86mm Single Gang Faceplate with Shuttered module 2 x RJ45 White
9.00 AEDAdd to cartLEVITON MMCWDOUNI071
86 x 86mm Single Gang Faceplate with Shuttered module 2 x RJ45 White
DESCRIPTION
Leviton’s UK style outlets and accessories have been designed to be used in conjunction with our extensive snap-in-jack range, from Cat 5 through to Cat 8. The range is manufactured using robust and durable ABS plastic.
• Supplied in both UNI and Integrated ranges
• Manufactured in ABS plastic
• Single and double gang options
• Faceplates are supplied with M3.5 fixing screws
• Faceplate mounting holes countersunk with pitch of 60.3mm for single and 120.6mm for double gang
• Alternative colors available on request N424.532 Nexans UK Style Backbox Single Gang White
9.00 AEDAdd to cartNexans N424.532
UK Style Backbox Single Gang White
DESCRIPTION
LANmark Snap-In Modules in standard UK styles
· 25 x 50 mm angled and flat shuttered modules for 1 LANmark Snap-In connector
· LJ6C angled and flat shuttered modules for 1 LANmark Snap-In connector
· 50 x 50 mm angled shuttered modules for 2 LANmark Snap-In connectors- BELDEN, Cat6 Accessories, Cat6 Modules & Outlets, Cat6a Accessories, Faceplates & Back Boxes, Structured Networking
NN01520 BELDEN Single Faceplate, White, Empty (WIFI WT2)
9.00 AEDAdd to cartBELDEN NN01520
Single Faceplate, White, Empty (WIFI WT2)
DESCRIPTION
6C (38.5x25mm) Modular Outlet Faceplate
Height: 86 mm
Width: 86 mm
Depth: 10 mm
Packaging: Individually packaged in a plastic bag. NN01521 BELDEN Faceplate 6C Outlet
8.00 AEDAdd to cartBELDEN NN01521
Faceplate 6C Outlet
Product Description
6C (38.5x25mm) Modular Outlet FaceplateHeight: 86 mm
Width: 86 mm
Depth: 10 mm
Packaging: Individually packaged in a plastic bag.Footprint/Type: KeyConnect & MDVO
Plug /Jack Compatibility: RJ45
