Description
D-Link NCB-C6UGRYR1-05
D-Link Cat6 UTP 24AWG Patch Cord, 0.5M
SPECIFICATIONS
• 4 Pairs Unshielded Twisted Pair (UTP) Cable
• Conductor Metal: Bare Copper
• Color Code: Gray
• Conductor: 24 AWG
• Insulation Material: HD-PE
• Jacket Material: PVC UL94V-0
• Heat-resistant: 60oC minimum (Temperature limited)
MODULAR CONNECTOR/PLUG
• RJ-45 8P for Transparence color.
• Gold plated: 30U”
• Contact blade: Phosphor Bronze
• Temperature range: -10 ~ 80oC
• Dielectric withstanding voltage: 500V AC
• Insulation resistance: 35M Ohm (max.)
• Durability: 750 matching cycles
• Cable-to-plug tensile strength: 20lbs (89N) (min.)
• UL applications: 250V AC, 2A (max.)
• Polycarbonate (PC) UL94-V-0
