FSC24 Panduit Splice Chip 24port Fusion Splices W/Level

Nexans N205.624

LANmark-OF Snap-in Adapter DSC-DSC Single mode

Description
LANmark-OF snap-in adapters have been designed for snapping into the
modular OF patch panels and ZD boxes. They are available in single SC,
dual SC, LC duplex and MT-RJ version. The 2 Small Form Factor connector
types offer double density, as two fiber connections are offered on the SCtype
footprint. Installation time is saved as the snap-in concept replaces
the time-consuming screwing attachment of coupling devices.
Materials
· Adapter Housing: PBT, 15% Glass
· Sleeve Holder: PBT, 20% Glass
· Dust Cap: PP
· Spring:SUS 304 CSP 3/4 H
· PB Sleeve: PB – inner diameter 2,48mm – length 11.4mm
· Zirconia Sleeve: ZA Ceramic – inner diam.: 2.48mm -length11.4mm
Technical Specifications
Insertion Loss: < 0.2 dB
Sleeve Preservation Strength: 2.0 ~ 5.9N (200gf ~600gf)
JIS Z9015 standard l: 1 time pull out
NAMl test AQL = 0.25%
Plug Connect/Disconnect Strength: Less than 19.6N (2Kgf)
Sealing Pull Strength: Less than 98.0N (10Kgf)
Plug Removal Strength: Less than 68.6N (7Kgf)
